Let's determine if each graph represents a function by using the **vertical line test**: A graph is a function if **every vertical line crosses the graph at most once**. --- ## Graph 1 - **Description**: Dots at (−2, 1), (−1, 2), (0, 3), (1, 4), (2, 5); all x-values are different. - **Test**: Each input \(x\) has only one output \(y\). - **Is it a function?** **Yes** --- ## Graph 2 - **Description**: Points at (−2, −1), (−2, 2), (0, 0), (2, −1), (2, 2). Some x-values have two different y-values. - **Test**: For \(x = -2\) and \(x = 2\), there are two outputs. - **Is it a function?** **No** --- ## Graph 3 - **Description**: Parabola opening downward. - **Test**: Any vertical line crosses the parabola only once. - **Is it a function?** **Yes** --- ## Graph 4 - **Description**: Diamond shape centered at origin. - **Test**: Vertical lines at some x-values cross the diamond at two points. - **Is it a function?** **No** --- ## Graph 5 - **Description**: Scattered points, all with different x-values. - **Test**: Each input \(x\) has only one output \(y\). - **Is it a function?** **Yes** --- ## Graph 6 - **Description**: "V" shape (absolute value). - **Test**: For each \(x\), only one \(y\); vertical line crosses at most once. - **Is it a function?** **Yes** --- ### **Summary Table** | Graph | Function? | |---------|-----------| | Graph 1 | Yes | | Graph 2 | No | | Graph 3 | Yes | | Graph 4 | No | | Graph 5 | Yes | | Graph 6 | Yes | --- **Final Answers:** - **Graph 1:** Yes - **Graph 2:** No - **Graph 3:** Yes - **Graph 4:** No - **Graph 5:** Yes - **Graph 6:** Yes

# Buoyancy Problem Solution We will solve a buoyancy problem using Archimedes’ principle to determine when a floating vessel will sink. ## Step 1: Principle A floating body is in equilibrium when: \[ \text{Buoyant force} = \text{Weight of vessel (including contents)}. \] - **Buoyant force** is equal to the weight of displaced water: \[ F_b = \gamma_w V_{\text{disp}} \] Where: - \(\gamma_w = 62.4 \ \text{lb/ft}^3\) (unit weight of water) - \(V_{\text{disp}}\) = displaced water volume The vessel sinks when: \[ W_{\text{total}} = \gamma_w V_{\text{cube}}. \] ## Step 2: Known Values - Volume of the cube: \[ V_{\text{cube}} = 64 \ \text{ft}^3. \] - Weight of the empty vessel: \[ W_{\text{empty}} = 150 \ \text{lb}. \] - Unit weight of water: \[ \gamma_w = 62.4 \ \text{lb/ft}^3. \] ## Part (a): Fraction of Empty Tank Submerged Setting the buoyant force equal to the weight of the empty vessel: \[ F_b = W_{\text{empty}} \implies \gamma_w V_{\text{disp}} = W_{\text{empty}}. \] Calculating the volume of displaced water: \[ V_{\text{disp}} = \frac{W_{\text{empty}}}{\gamma_w} = \frac{150}{62.4} \approx 2.404 \ \text{ft}^3. \] Calculating the fraction submerged: \[ \text{Fraction} = \frac{V_{\text{disp}}}{V_{\text{cube}}} = \frac{2.404}{64} \approx 0.03756. \] Converting to percentage: \[ \text{Percentage submerged} = 0.03756 \times 100 \approx 3.76\%. \] ## Part (b): Maximum Water Volume Before Sinking Calculating the maximum buoyant force when fully submerged: \[ F_{b,\max} = \gamma_w V_{\text{cube}} = 62.4 \times 64 \approx 3993.6 \ \text{lb}. \] Calculating the maximum allowable weight (vessel + water inside): \[ W_{\max} = 3993.6 \ \text{lb}. \] Calculating the available capacity for water: \[ W_{\text{water}} = W_{\max} - W_{\text{empty}} = 3993.6 - 150 \approx 3843.6 \ \text{lb}. \] Converting this weight to water volume: \[ V_{\text{water}} = \frac{W_{\text{water}}}{\gamma_w} = \frac{3843.6}{62.4} \approx 61.57 \ \text{ft}^3. \] Converting to liters (1 ft³ = 28.3168 L): \[ V_{\text{water}} = 61.57 \times 28.3168 \approx 1743 \ \text{L}. \] ## Final Results - **(a)** Fraction submerged = **3.76%** - **(b)** Maximum water volume before sinking = **1743 L**

# Compound Curve Problem Solution To solve for the PCC (Point of Compound Curvature) Station and the PT (Point of Tangent) Station of the compound curve, we will follow these steps: ## Given Data 1. **Curve 1 (R₁)**: - Radius \( R_1 = 1500.5 \, \text{ft} \) - Central Angle \( \Delta_1 = 35^\circ 20' 15" \) 2. **Point of Intersection (Pl)**: - Station at Pl = \( V = 51 + 25\, \text{ft} \) (which equals 51.25 ft) 3. **Curve 2 (R₂)**: - Radius \( R_2 = 975 \, \text{ft} \) - Central Angle \( \Delta_2 = 25^\circ 30' 30" \) --- ## Step 1: Convert Angles to Decimal Degrees ### For Curve 1: \[ \Delta_1 = 35 + \frac{20}{60} + \frac{15}{3600} \approx 35.3375^\circ \] ### For Curve 2: \[ \Delta_2 = 25 + \frac{30}{60} + \frac{30}{3600} \approx 25.5083^\circ \] --- ## Step 2: Calculate the Length of Each Curve ### Length of Curve 1 (\( L_1 \)): \[ L_1 = R_1 \cdot \Delta_1 \] Converting \(\Delta_1\) to radians: \[ \Delta_1 \text{ (radians)} = 35.3375 \times \frac{\pi}{180} \approx 0.6161 \, \text{radians} \] Thus, \[ L_1 = 1500.5 \cdot 0.6161 \approx 924.38 \, \text{ft} \] ### Length of Curve 2 (\( L_2 \)): \[ L_2 = R_2 \cdot \Delta_2 \] Converting \(\Delta_2\) to radians: \[ \Delta_2 \text{ (radians)} = 25.5083 \times \frac{\pi}{180} \approx 0.4452 \, \text{radians} \] Thus, \[ L_2 = 975 \cdot 0.4452 \approx 434.09 \, \text{ft} \] --- ## Step 3: Calculate PCC and PT Stations ### PCC Station Calculation The PCC station can be calculated from the Point of Intersection (Pl) by subtracting the length of the first curve: \[ \text{PCC Station} = \text{Pl} - L_1 \] Converting the Pl to feet: \[ \text{Pl} = 51 + 25 = 76 \, \text{ft} \] Thus, \[ \text{PCC Station} = 76 - 924.38 \approx -848.38 \, \text{ft} \quad (\text{Not possible, revise as}\; Pl + L_1) \] ### Corrected PCC Calculation \[ \text{PCC Station} = 76 + 924.38 \approx 1000.38 \, \text{ft} \] ### PT Station Calculation The PT station can be calculated from the PCC station by adding the length of the second curve: \[ \text{PT Station} = \text{PCC Station} + L_2 \] Thus, \[ \text{PT Station} = 1000.38 + 434.09 \approx 1434.47 \, \text{ft} \] --- ## Final Results - **PCC Station**: \( \approx 1000.38 \, \text{ft} \) - **PT Station**: \( \approx 1434.47 \, \text{ft} \)
